Benefits

•     Perfect shape of the end pallet
•     Between 1 and 1’5 kW of energy saving in the elevation platform, 20 % to 25% consumption reduction on the gearboxes and longer lasting of the mechanical elements due to the use of low friction surfaces.
•     Flexibility and quickness on format’ changes
•     Smooth, accurate and quiet operation
•     Simple and user friendly operation
•     Rigid and accurate machine
•     Quick and easy change of belt conveyors

Options

•     Carton sheet dispenser on empty and/or full pallet
•     Dispensing and stapling of a PE sheet (from a roll), on empty pallet
•     Automatic dispenser of an interlayer anti-sliding paper-sheet (from a roll)
•     Anti-corrosive versions to handle highly aggressive products
•     ATEX versions for installation in Classified Areas
•     Version for pallet-less applications

Features

•     Outputs up to 2.000 bags/hour depending on palletizing formats and number of layers
•     Bag’s conditioning system and turning device according to the product, type of bag and required output.
•     Counterweighed elevation platform, driven by motor-gear with frequency inverter
•     Layer forming zone equipped of a double slide-gate with a low friction coating made of polyethylene (PE-1000)
•     Side and frontal forming dams, motorized and driven by double rack
•     Top flattening of each new layer against the sliding gates
•     Pallet’s centering device at the elevation platform
•     Automatic pallet dispenser, entrance and exit roller conveyors
